Ultra High Torque Stirrer ST-1800DF
Contact our expert for more informations.
When the overhead stirrer is installed in a higher and farther position, such as connecting with the reaction systems, the operator can not easily to operate.
We have developed and designed a remotely controllable stirrer that separates the stirring part from the control part and makes it easier to operate through a remote panel.
(r.240720)
Technical features
- Speed accuracy (rpm): ± 1rpm
- Torque accuracy (in-lb): ± 5%
- Speed range (rpm): Low: 12~360; High: 361~1800
- Torque (N-cm): Low: 565, High: 113
- Maximum Viscosity (cps): 150000
- Maximum Torque (N-cm): 565
- Chuck range max. diameter (mm): 10
- Maximum capacity (L) H2O: 40
- Output power (W): 150
- Dimensions of the remote panel: 150×100mm
- 2m cable lenght
- Cable connection mode: Quick connector
- Control and display parameters: stirring speed, torque and Stirring mode
- Brushless DC motor
- Totally enclosed and compact metal casing
- Bright TFT screen, which can display stirring speed and torque
- Transmission can be switched between low speed/ high torque, and high speed / low torque
- Easily adjustable spinning chuck
- Precise speed adjustment
- Set speed can be maintained when viscosity of liquid changes
- Easy and time saving impeller adjustments
- Digital and analog interface available
- Monitoring and control via PC software
Industries
Chemical
Herbal and phytotherapic
Pharmaceutical
Applications
Stirring
Reaction
Chemical synthesis
Product codes
| Steroglass code | Brand code | Description |
|---|---|---|
| SQAO080339 | ST100600F-222E | ST-1800DF |
